Description
Stainless steel mooring shackle with sleek shape designed to pass through fairleads.
Wire rope in the sheave. Fiber rope around the body.
Sizes: 90 and 120 Metric Tons.
| Model | 90M | 120M |
|---|---|---|
| Forerunner Circ. (inches) | 6–9 | 9–11 |
| A (mm) | 255 | 310 |
| B (mm) | 97 | 121 |
| C (mm) | 120 | 130 |
| D (mm) | 65 | 82 |
| E (mm) | 67 | 90 |
| F (mm) | 100 | 128 |
| R (mm) | 34 | 45 |
| Breaking Load M/Tons | 90 | 120 |
| Proof Load M/Tons | 55 | 70 |
| Safe Working Load M/Tons | 30 | 40 |
| Weight | 7.8 kg (17.2 lbs.) | 13.3 kg (29 lbs.) |
